Auto Ace Double Up – 16” x 20” Automatic Dual Station Heat Press
Auto Ace Double Up – 16” x 20” Automatic Dual Station Heat Press
Couldn't load pickup availability
Ace Double Up 16" x 20" Fully Automatic Dual Platen Heat Press
The Ace Double Up 16" x 20" Fully Automatic Dual Platen Heat Press is built for decorators who need speed, consistency, and dependable commercial production. Its fully automatic dual-platen design allows one station to be loaded while the other is pressing, helping reduce downtime and improve workflow.
Technical Specifications
Commercial Performance
Designed for continuous commercial use, this press provides consistent heat distribution and pressure across the entire platen, making it ideal for high-volume DTF transfer production, HTV application, sublimation, and screen printed transfers.
Whether you're decorating a handful of garments or producing hundreds each day, the Ace Double Up helps deliver professional-quality results with every press.
Compare Ace Double Up Heat Presses
Not sure which dual platen heat press is right for your shop? Compare the Ace Double Up Semi-Pneumatic and Auto Ace Double Up Fully Automatic heat presses below to choose the best fit for your production volume, workflow, and growth goals.
| Feature | Ace Double Up Semi-Pneumatic | Auto Ace Double Up Fully Automatic |
|---|---|---|
| Best For | Growing print shops | High-volume commercial production |
| Operation | Semi-Pneumatic | Fully Automatic |
| Platen Size | 16" × 24" | 16" × 20" |
| Dual Platen Design | Yes | Yes |
| Voltage | 110V | 110V |
| Air Compressor Required | Yes | Yes — 1 gallon silent compressor recommended |
| Maximum Air Pressure | 150 PSI | 150 PSI |
| Temperature Range | 0°–450°F | 0°–450°F |
| Timer Range | 0–180 seconds | 0–180 seconds |
| Independent Digital Controls | Yes | Yes |
| Commercial Steel Construction | Yes | Yes |
| Machine Dimensions | 40"W × 31"D × 55"H | 40"W × 31"D × 55"H |
| Machine Weight | 450 lbs | 450 lbs |
| Shipping Weight | 500 lbs | 500 lbs |
| Operator Effort | Moderate | Minimal |
| Production Speed | High | Maximum |
| Recommended For |
Small to medium production shops
Best Value |
Large production facilities and contract decorators
Highest Output |
Choose the Semi-Pneumatic Model If You...
- Want commercial production at a lower investment
- Have one dedicated press operator
- Need faster output than a manual heat press
- Press DTF, screen printed transfers, HTV, or sublimation
- Want consistent pressure with less operator fatigue
Choose the Fully Automatic Model If You...
- Press garments all day
- Want maximum production speed
- Need repeatable results every cycle
- Want the operator focused on loading garments
- Plan to scale into higher-volume production
At a Glance
| If you want the lowest investment | Choose the Semi-Pneumatic |
| If you want the highest production speed | Choose the Fully Automatic |
| If you want less operator fatigue | Choose the Fully Automatic |
| If you want commercial-quality pressing | Both models are a strong fit |
| If you need DTF, screen print transfers, sublimation, or HTV | Both models can handle the job |
