Ace Double Up – 16” x 24” Semi Pneumatic Dual Platen Heat Press
Ace Double Up – 16” x 24” Semi Pneumatic Dual Platen Heat Press
Couldn't load pickup availability
Ace Double Up 16" x 24" Semi-Pneumatic Dual Platen Heat Press
Increase production, reduce operator fatigue, and achieve professional-quality results with the Ace Double Up 16" x 24" Semi-Pneumatic Dual Platen Heat Press. Designed for high-volume apparel decorators, this commercial-grade heat press features a dual-platen system that allows one platen to be loaded while the other is pressing.
Whether you're producing DTF transfers, screen printed transfers, heat transfer vinyl, or sublimation apparel, the Ace Double Up delivers consistent heat and pressure across the entire platen for vibrant, durable results.
Features
- Large 16" x 24" dual-platen design
- Semi-pneumatic operation reduces fatigue
- Consistent heat and pressure
- Digital temperature and timer controls
- Heavy-duty commercial construction
- Ideal for high-volume production
- Compatible with DTF transfers
- Works with HTV, sublimation, and screen print transfers
Technical Specifications
Perfect For
- DTF transfers
- Screen printed transfers
- Heat transfer vinyl
- Sublimation transfers
- Team uniforms
- Spirit wear
- Corporate apparel
- Contract printing
Why Choose the Ace Double Up?
The dual-platen design allows operators to prepare the next garment while another is being pressed, significantly reducing downtime and increasing productivity. Combined with semi-pneumatic operation, precise digital controls, and a large pressing surface, the Ace Double Up helps businesses produce more garments with greater consistency and less operator fatigue.
At Ace DTF, we understand apparel decoration because we do it every day. Our experienced team is available to help you choose the right equipment and answer questions before and after your purchase.
Compare Ace Double Up Heat Presses
Not sure which dual platen heat press is right for your shop? Compare the Ace Double Up Semi-Pneumatic and Auto Ace Double Up Fully Automatic heat presses below to choose the best fit for your production volume, workflow, and growth goals.
| Feature | Ace Double Up Semi-Pneumatic | Auto Ace Double Up Fully Automatic |
|---|---|---|
| Best For | Growing print shops | High-volume commercial production |
| Operation | Semi-Pneumatic | Fully Automatic |
| Platen Size | 16" × 24" | 16" × 20" |
| Dual Platen Design | Yes | Yes |
| Voltage | 110V | 110V |
| Air Compressor Required | Yes | Yes — 1 gallon silent compressor recommended |
| Maximum Air Pressure | 150 PSI | 150 PSI |
| Temperature Range | 0°–450°F | 0°–450°F |
| Timer Range | 0–180 seconds | 0–180 seconds |
| Independent Digital Controls | Yes | Yes |
| Commercial Steel Construction | Yes | Yes |
| Machine Dimensions | 40"W × 31"D × 55"H | 40"W × 31"D × 55"H |
| Machine Weight | 450 lbs | 450 lbs |
| Shipping Weight | 500 lbs | 500 lbs |
| Operator Effort | Moderate | Minimal |
| Production Speed | High | Maximum |
| Recommended For |
Small to medium production shops
Best Value |
Large production facilities and contract decorators
Highest Output |
Choose the Semi-Pneumatic Model If You...
- Want commercial production at a lower investment
- Have one dedicated press operator
- Need faster output than a manual heat press
- Press DTF, screen printed transfers, HTV, or sublimation
- Want consistent pressure with less operator fatigue
Choose the Fully Automatic Model If You...
- Press garments all day
- Want maximum production speed
- Need repeatable results every cycle
- Want the operator focused on loading garments
- Plan to scale into higher-volume production
At a Glance
| If you want the lowest investment | Choose the Semi-Pneumatic |
| If you want the highest production speed | Choose the Fully Automatic |
| If you want less operator fatigue | Choose the Fully Automatic |
| If you want commercial-quality pressing | Both models are a strong fit |
| If you need DTF, screen print transfers, sublimation, or HTV | Both models can handle the job |
Before You Order
Please make sure your artwork is print-ready, properly sized, and has no unwanted background. If your file needs cleanup, resizing, color adjustment, or background removal, contact us before placing your order.
Complete Your DTF Setup
Get everything you need for professional DTF printing, pressing, and production.
